we can quote 2MM308WI bearing price , Timken price d:40.000 *D:90.000 *B:23.000 mm ,

2MM308WI

31308/31308

2MM308WI bearinginquiry

Design Units

Metric

Bearing Weight

1.3000 lb
0.6000 Kg

D - Outer Diameter

3.5433 in
90.000 mm

d - Bore

1.5748 in
40.000 mm

C - Inner Ring Width

0.9055 in
23.000 mm

B - Outer Ring Width

0.9055 in
23.000 mm

do - Ball Diameter

0.5906 in
15.00 mm

Z - Number of Balls Per Row

R - Inner Ring To Clear Radius¹

0.06 in
1.50 mm

r - Outer Ring To Clear Radius²

0.06 in
1.50 mm

da - Inner Ring Backing Diameter

1.94 in
49.3 mm

Da - Outer Ring Backing Diameter

3.20 in
81.30 mm

Ce - Dynamic Radial Rating¹

13400 lbf
59700 N

C1 ISO - Dynamic Radial Rating

12200 lbf
54300 N

C0 - Static Radial Rating

7880 lbf
35000 N

Limiting Speed (Grease)

16900 rpm

Limiting Speed (Oil)

33800 rpm

Cg - Geometry Factor¹

0.0664

Sales the 2MM308WI bearings, condition monitoring and technical supports. we can assure the quality of the Timken 2MM308WI bearings we provide, at the same time guarantee the price is always competitive. As our valued customers, you always have a peace in mind when using 2MM308WI bearings..

more↓

we can quote 2MM308WI bearing price , Timken price d:40.000 *D:90.000 *B:23.000 mm , Previous:3MMC307WI Timken Next:3MMC307WI Timken

Brand:

TIMKEN Bearing

Category:

Tapered Roller Bearings

Model:

31308/31308

40.000 mm

90.000 mm

23.000 mm

Cr:

79000 N

C0r:

88100 N

0.72 kg
