Boundary Dimensions

d 17 mm Bore diameter
D 40 mm Outside diameter
B 16 mm Width
r (min.) 0.6 mm Chamfer dimension
Basic Load Ratings
Cr 10900 N Basic dynamic load rating

C0r 2420 N Basic static load rating

Speeds
Grease 16000 min-1 Grease lubrication
Oil (Oil-bath) 20000 min-1 Oil-bath lubrication
Abutment and Fillet Dimensions
da (min.) 21 mm Diameter of shaft abutment
Da (max.) 36 mm Diameter of housing abutment
ra (max.) 0.6 mm Radius of shaft or housing fillet
Calculation factors
e 0.5 Constant
Y2 1.9 Axial load Factors
Y3 1.3 Axial load Factors
Y0 1.3 Axial load Factors
Mass
(approx.) 0.085 kg
